Model 4719
BNC (Female) To Bantam
Plug Adapter
FEATURES:
?
?
?
?
Converts Bantam jacks to BNC for coaxial cable compatibility
BNC shell is tarnish resistant
BNC materials include gold plated Beryllium Copper for superior electrical performance
Schematic: Tip to BNC center conductor, ring to BNC Shell, sleeve - floating
MATERIALS:
BNC: Body - Brass, nickel plated
Center Contact – Beryllium Copper, gold plated
Insulation: ABS, molded to BNC receptacle and plug, color: black
Bantam Plug: Brass
RATINGS:
Operating Temperature: +50°C (+122°F)
Operating Voltage: 500 V Peak
ORDERING INFORMATION : Model 4719
All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (,51 mm), .xxx = ± .005” (,127 mm).
All specifications are to the latest revisions. Specifications are subject to change without notice.
Registered trademarks are the property of their respective companies. Made in USA
6/10/02 SY/EH/LS
Last saved by PN
Sales: 800-490-2361 Fax: 888-403-3360
Technical Assistance: 800-241-2060
Pomona ACCESS 90399 (800) 444-6785 or (425) 446-6010
More drawings available at www.pomonaelectronics.com
S:\Engineering\Release\DataSheets\FlukeDataSheet \d4719_1_02.doc
Page 1 of 1
